General Specifications – Name – AMD Ryzen™ 5 9600XFamily – RyzenSeries – Ryzen 9000 SeriesForm Factor – Desktops , Boxed ProcessorMarket Segment – Enthusiast DesktopAMD PRO Technologies – NoConsumer Use – YesRegional Availability – GlobalFormer Code Name – Granite Ridge AM5Architecture – Zen 5# of CPU Cores – 6Multithreading (SMT) – Yes# of Threads – 12Max. Boost Clock – Up to 5.4 GhzBase Clock – 3.9 GhzL1 Cache – 480 KBL2 Cache – 6 MBL3 Cache – 32 MBDefault TDP – 65WProcessor Technology for CPU Cores – TSMC 4nm FinFETProcessor Technology for I/O Die – TSMC 6nm FinFETPackage Die Count – 2Unlocked for Overclocking – YesAMD EXPO™ Memory Overclocking Technology – YesPrecision Boost Overdrive – YesCurve Optimizer Voltage Offsets – YesAMD Ryzen™ Master Support – YesCPU Socket – AM5Supporting Chipsets – A620 , X670E , X670 , B650E , B650 , X870E , X870CPU Boost Technology – Precision Boost 2Instruction Set – x86-64Supported Extensions – AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64Thermal Solution (PIB) – Not IncludedRecommended Cooler – Premium air cooler recommended for optimal performanceMax. Operating Temperature (Tjmax) – 95°C*OS Support – Windows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-BitConnectivity – Native USB 3.2 Gen 2 (10Gbps) Ports – 4Native USB 2.0 (480Mbps) Ports – 1PCI Express® Version – PCIe® 5.0Native PCIe® Lanes (Total/Usable) – 28, 24Additional Usable PCIe Lanes from Motherboard – X870E 8x Gen4X870 4x Gen4X670E 12x Gen4X670 12x Gen4B650E 8x Gen4B650 8x Gen4NVMe Support – Boot , RAID0 , RAID1 , RAID5 , RAID10System Memory Type – DDR5Memory Channels – 2Max. Memory – 192 GBSystem Memory Subtype – UDIMMMax Memory Speed – 2x1R DDR5-56002x2R DDR5-56004x1R DDR5-36004x2R DDR5-3600ECC Support – Yes (Requires mobo support)Graphics Compatibility – Graphics Model – AMD Radeon™ GraphicsGraphics Core Count – 2Graphics Frequency – 2200MhzUSB Type-C® DisplayPort™ Alternate Mode – YesSupported Technologies – AMD EXPO™ Technology , AMD Ryzen™ TechnologiesWarranty – 3 YearsNote** – **Prices, Specifications & Features are subject to change without notice

Processor – System Memory – System Memory Specification : 3200MHz System Memory Type : DDR4Specifications – # of CPU Cores : 8 # of Threads : 16 Base Clock : 3.9GHz Max Boost Clock : Up to 4.7GHz Total L2 Cache : 4MB Total L3 Cache : 32MB Unlocked : Yes CMOS : TSMC 7nm FinFET Package : AM4 PCI Express? Version : PCIe 4.0 Default TDP / TDP : 105WFoundation – Product Family : AMD Ryzen? Processors Product Line : AMD Ryzen? 7 Desktop Processors OPN PIB : 100-100000279WOF Launch Date : 7/2020**Warranty – 3 years from ManufactureNote** – Price, feature and specifications are subject to change without notice.

Specification – General Specifications – Platform: DesktopProduct Family: AMD Ryzen™ ProcessorsProduct Line: AMD Ryzen™ 7 Desktop Processors# of CPU Cores: 8# of Threads: 16Max. Boost Clock: Up to 4.6GHzBase Clock: 3.4GHzTotal L1 Cache: 512KBTotal L2 Cache: 4MBTotal L3 Cache: 32MBDefault TDP: 65WProcessor Technology for CPU Cores: TSMC 7nm FinFETUnlocked for Overclocking: YesCPU Socket: AM4Socket Count: 1PThermal Solution (PIB): Not IncludedMax. Operating Temperature (Tjmax): 90°COS Support: Windows 11 – 64-Bit Edition, Windows 10 – 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-BitConnectivity – PCI Express® Version: PCIe 4.0System Memory Type: DDR4Memory Channels: 2Max Memory Speed:2x1R – DDR4-32002x2R – DDR4-32004x1R – DDR4-29334x2R – DDR4-2667Key Features – Supported Technologies:AMD StoreMI TechnologyAMD “Zen 3” Core ArchitectureAMD Ryzen™ VR-Ready PremiumWarranty – 3 YearsNote* – Price, feature and specifications are subject to change without notice.

Specification – General Specifications – Platform: Boxed ProcessorProduct Family: AMD Ryzen™ ProcessorsProduct Line: AMD Ryzen™ 7 Desktop Processors# of CPU Cores: 8# of Threads: 16Max. Boost Clock: Up to 4.1GHzBase Clock: 3.0GHzTotal L1 Cache: 512KBTotal L2 Cache: 4MBTotal L3 Cache: 96MBDefault TDP: 105WProcessor Technology for CPU Cores: TSMC 7nm FinFETCPU Socket: AM4Socket Count: 1PThermal Solution (PIB): Not IncludedMax. Operating Temperature (Tjmax): 90°COS Support: Windows 11 – 64-Bit Edition, Windows 10 – 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-BitConnectivity – PCI Express® Version: PCIe 4.0System Memory Type: DDR4Memory Channels: 2Max Memory Speed:2x1R – DDR4-32002x2R – DDR4-32004x1R – DDR4-29334x2R – DDR4-2667Key Features – Supported TechnologiesAMD StoreMI TechnologyAMD “Zen 3” Core ArchitectureAMD Ryzen™ Master UtilityAMD Ryzen™ VR-Ready PremiumWarranty – 3 YearsNote* – Price, feature and specifications are subject to change without notice.

Specification – General Specifications – Name: AMD Ryzen 7 5800XTFamily: RyzenSeries: Ryzen 5000 SeriesForm Factor: Boxed Processor , DesktopsMarket Segment: Enthusiast DesktopConsumer Use: YesCommercial Use: NoRegional Availability: GlobalFormer Codename: VermeerArchitecture: Zen 3# of CPU Cores: 8Multithreading (SMT): Yes# of Threads: 16Max. Boost Clock: Up to 4.8 GHzBase Clock: 3.8 GHzL1 Cache: 512 KBL2 Cache: 4 MBL3 Cache: 32 MBDefault TDP: 105WProcessor Technology for CPU Cores: TSMC 7nm FinFETProcessor Technology for I/O Die: 12nm (Globalfoundries)CPU Compute Die (CCD) Size: 74mm²I/O Die (IOD) Size: 125mm²Package Die Count: 2Unlocked for Overclocking: YesCPU Socket: AM4Supporting Chipsets: X570 , B550 , A520 , X470 , B450CPU Boost Technology: Precision Boost 2Instruction Set: x86-64Supported Extensions: AES , AMD-V , AVX , AVX2 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64Thermal Solution (PIB): AMD Wraith PrismMax. Operating Temperature (Tjmax): 90°C*OS Support: Windows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-BitConnectivity – Native USB 3.2 Gen 2 (10Gbps) Ports: 4Native USB 3.2 Gen 1 (5Gbps) Ports: 0Native USB 2.0 (480Mbps) Ports: 0Native SATA Ports: 2PCI Express® Version: PCIe® 4.0Native PCIe® Lanes (Total/Usable): 24 , 20Additional Usable PCIe Lanes from Motherboard:amd_x570           16x Gen 4amd_x470           2x Gen 3, 8x Gen 2NVMe Support: Boot , RAID0 , RAID1 , RAID10System Memory Type: DDR4Memory Channels: 2Max. Memory: 128 GBSystem Memory Subtype: UDIMMMax Memory Speed:2x1R      DDR4-32002x2R      DDR4-32004x1R      DDR4-29334x2R      DDR4-2667ECC Support: Yes (Requires mobo support)Graphics Capabilities – Graphics Model: Discrete Graphics Card RequiredWarranty – 3 YearsNote* – Price, feature and specifications are subject to change without notice.

Platform – DesktopNo of CPU Cores – 8No of Threads – 16Max Boost Clock – Up to 5.3GhzBase Clock – 3.8 GhzL1 Cache – 512KbL2 Cache – 8MbL3 Cache – 32MbDefault TDP – 65WProcessor Technology for CPU Cores – TSMC 5nm FinFETUnlocked for Overclocking – YesCPU Socket – AM5Thermal Solution (PIB) – AMD Wraith PrismMax. Operating Temperature (Tjmax) – 95°CLaunch Date – 1/14/2023*OS Support – Windows 11 – 64-Bit EditionWindows 10 – 64-Bit EditionRHEL x86 64-BitUbuntu x86 64-Bit*Operating System (OS) support will vary by manufacturer.PCI Express® Version – PCIE 5.0System Memory Type – DDR5Memory Channels – 2Max Memory Speed – 2x1RDDR5-52002x2RDDR5-52004x1RDDR5-36004x2RDDR5-3600Graphics Model – AMD Radeon™ GraphicsGraphics Core Count – 2Graphics Frequency – 2200 MhzGPU Base – 400 MhzWarranty – 3 YearsNote** – **Prices, Specifications & Features are subject to change without notice

Model – AMD Ryzen 7 8700FP/N – 100-100001590BOXFamily – RyzenSeries – Ryzen 8000 SeriesForm Factor – DesktopsAMD PRO Technologies – NoConsumer Use – YesArchitecture – Zen 4# of CPU Cores – 8Multithreading (SMT) – Yes# of Threads – 16Max. Boost Clock – Up to 5 GHzBase Clock – 4.1 GHzL2 Cache – 8 MBL3 Cache – 16 MBDefault TDP – 65WAMD Configurable TDP (cTDP) – 45-65WProcessor Technology for CPU Cores – TSMC 4nm FinFETCPU Compute Die (CCD) Size – 178mm²Package Die Count – 1Unlocked for Overclocking – YesAMD EXPO Memory Overclocking Technology – YesPrecision Boost Overdrive – YesCurve Optimizer Voltage Offsets – YesAMD Ryzen Master Support – YesCPU Socket – AM5CPU Boost Technology – Precision Boost 2Instruction Set – x86-64Supported Extensions – AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSSE3 , SSE4.1 , SSE4.2 , SSE4A , x86-64Max. Operating Temperature (Tjmax) – 95°COS Support – Windows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-BitConnectivity – Native USB 4 (40Gbps) Ports – 2Native USB 3.2 Gen 2 (10Gbps) Ports – 2Native USB 2.0 (480Mbps) Ports – 1PCI Express Version – PCIe 4.0Native PCIe Lanes (Total/Usable) – 20 , 16NVMe Support – Boot , RAID0 , RAID1System Memory Type – DDR5Memory Channels – 2Max. Memory – 256 GBSystem Memory Subtype – UDIMMMax Memory Speed – 2x1R  DDR5-52002x2R  DDR5-52004x1R  DDR5-36004x2R  DDR5-3600Graphics Capabilities – Graphics Model – Discrete Graphics Card RequiredAMD SmartAccess Memory – AvailableAI Engine Capabilities – Brand Name – AMD Ryzen AIAMD Ryzen AI – Available when paired with a compatible Radeon graphics card with AI accelerationPerformance – Up to 16 TOPSSecurity, Virtualization, and Manageability – AMD Enhanced Virus Protection (NX bit) – YesWarranty – 3 yearsNote – *** Image use for reference only*** Features, Price, Specifications are subject to change without notice.

Specification – General Specifications – Regional Availability: GlobalPlatform: DesktopProduct Family: AMD Ryzen™ ProcessorsProduct Line: AMD Ryzen™ 7 8000 G-Series Desktop Processors with Radeon™ Graphics# of CPU Cores: 8# of Threads: 16Max. Boost Clock: Up to 5.1GHzBase Clock: 4.2GHzL2 Cache: 8MBL3 Cache: 16MBDefault TDP: 65WAMD Configurable TDP (cTDP): 45-65WProcessor Technology for CPU Cores: TSMC 4nm FinFETUnlocked for Overclocking: YesCPU Socket: AM5Max. Operating Temperature (Tjmax): 95°C*OS Support: Windows 11 – 64-Bit Edition, Windows 10 – 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit*Operating System (OS) support will vary by manufacturer.Connectivity – PCI Express® Version: PCIe® 4.0System Memory Type: DDR5Memory Channels: 2Max Memory Speed: 2x1R DDR5-5200 / 2x2R DDR5-5200 / 4X1R DDR5-3600 / 4x2R DDR5-3600Graphics Capabilities – Graphics Model: AMD Radeon™ 780MGraphics Core Count: 12Graphics Frequency: 2900 MHzAI Engine Capabilities – Brand Name: AMD Ryzen™ AIAMD Ryzen™ AI: AvailablePerformance: Up to 16 TOPSWarranty – 3 YearsNote* – Price, feature and specifications are subject to change without notice.
