B650 ATX with 14+2+1 phases, support for PCIe Gen5 M.2 (Blazing M.2), multiple M.2 slots, abundant USB (including Gen2x2 Type-C), Realtek 2.5G LAN and solid thermal armor. Great for mainstream-to-enthusiast AM5 builds. CTA: A2Z Computech can configure RAID/M.2 arrays, flash BIOS and stress-test storage setups.
| Model | ASRock B650 Pro RS |
|---|---|
| CPU Support / Socket | AMD Ryzen 7000 / 8000 / 9000 — Socket AM5 |
| Chipset | B650 |
| Memory Support | DDR5 up to 6200+ (OC); EXPO / XMP support |
| Max RAM | 128 GB |
| Memory Type | DDR5 |
| Expansion Slots (PCIe) | CPU: 1× PCIe4.0 x16; Chipset: 1× PCIe3.0 x16 (x4), 1× PCIe4.0 x1; 1× M.2 Key-E (WiFi) |
| Storage Support | 1× Blazing M.2 (PCIe Gen5 x4), 1× Hyper M.2 (PCIe Gen4 x4), 1× M.2 (PCIe Gen4 x2), 4× SATA3 |
| Graphics Output Options | 1× HDMI 2.1, 1× DisplayPort 1.4 |
| LAN | Realtek 2.5Gb (RTL8125 series) |
| Audio Codec | Realtek ALC897 (Nahimic) |
| USB Support (rear + front / totals) | Rear: 1× USB3.2 Gen2 Type-C (10Gb/s), 1× USB3.2 Gen2 Type-A (10Gb/s), 2× USB3.2 Gen1; 6× USB2.0 → Rear = 10. Front: 1× USB3.2 Gen2x2 Type-C (20Gb/s), 2× USB3.2 Gen1, 3× USB2.0 → Front = 6. Total = 16 |
| Internal I/O Headers (key) | SPI TPM header; 3× Addressable LED headers; RGB header; CPU fan; CPU/water pump fan; 4× chassis fan; 24-pin ATX; 8-pin + 4-pin CPU power; Thunderbolt AIC connector; Front Type-C header; etc. |
| Form Factor | ATX |
| Warranty | 3 Years |
