AM5 AORUS ATX with twin 12+2+2 VRM, PCIe5 x4 M.2, Wi-Fi6E, front USB-C 20Gbps and advanced thermal armor — balanced performance for mainstream enthusiasts. CTA: A2Z Computech can preflash EXPO profiles, run stress tests and deliver benchmarked AORUS systems.
| Model | Gigabyte B650 AORUS ELITE AX V2 (ATX) |
|---|---|
| CPU Support / Socket | AMD Socket AM5 — Supports Ryzen 7000/8000/9000 series. |
| Chipset | B650 |
| Memory Support | DDR5 support: listed OC profiles up to 8000/7800/7600/7200/7000/6800/6666/6600/6400/6200/6000/5600/5200/4800/4400 MT/s. |
| Max RAM | 192 GB (4× DIMMs, 48 GB single DIMM capacity listed). |
| Memory Type | DDR5 |
| Expansion Slots (PCIe) | CPU: 1× PCIe 4.0 x16 (PCIEX16); Chipset: 2× PCIe x16 (operating as x1/x4 per spec) |
| Storage Support | M2A_CPU: 1× PCIe5.0 x4; M2B_CPU: 1× PCIe4.0 x4; M2C_SB: 1× PCIe4.0 x4; 4× SATA 6Gb/s. |
| Graphics Output Options | 1× DisplayPort (DP1.4) + 1× HDMI (HDMI2.1) (resolutions in spec). |
| LAN | Realtek 2.5GbE LAN |
| Audio Codec | Realtek HD Audio codec (High Definition Audio) — multi-channel support. |
| USB Support (rear + front / totals) | Rear: 1× USB Type-C (USB3.2 Gen2), 2× USB3.2 Gen2 Type-A (red), 4× USB3.2 Gen1, 4× USB2.0 (back + hub counts). Chipset/internal: additional USB Type-C (Gen2x2 via internal header) and internal USB headers — Totals: Not aggregated. |
| Internal I/O Headers (key) | 1× 24-pin ATX, 1× 8-pin + 1× 4-pin CPU power, CPU fan + pump headers, 3× system fan, 3× M.2 sockets, front Type-C header, addressable RGB Gen2 headers, TPM header, Clear CMOS, Q-Flash Plus. |
| Form Factor | ATX (30.5 × 24.4 cm) |
| Warranty | 3 Years |
