Z790 ATX with twin 12+1+1 VRM, 3× M.2, 2.5GbE + Wi-Fi6E, Thunderbolt-ready headers and Q-Flash Plus — reliable performer for Intel platforms. CTA: A2Z Computech can configure multi-NVMe arrays, preflash BIOS and deliver certified workstation builds.
| Model | MSI Pro Z790-P WIFI |
|---|---|
| CPU Support / Socket | Intel® LGA 1700 — supports 14th/13th/12th Gen Intel Core, Pentium Gold, Celeron. |
| Chipset | Z790 |
| Memory Support | DDR5 — supports 7000+ (OC) / listed JEDEC speeds per spec. |
| Max RAM | 128 GB (4× DIMM) |
| Memory Type | DDR5 |
| Expansion Slots (PCIe) | 3× PCI-E x16 slots + 1× PCI-E x1 (PCI_E1 = PCIe5.0 x16 from CPU; others from chipset as described). |
| Storage Support | 4× M.2 slots (mix of CPU / chipset PCIe4.0) + 6× SATA 6Gb/s. |
| Graphics Output Options | 1× HDMI + 1× DisplayPort (dependent on CPU iGPU). |
| LAN | Intel 2.5Gbps LAN |
| Audio Codec | Realtek® ALC897 7.1-channel HD Audio. |
| USB Support (rear + front / totals) | USB: Rear & front enumerated in spec — e.g., 4× USB2.0 (rear) + 4× USB2.0 (front), 2× USB3.2 Gen1 Rear, 4× USB3.2 Gen1 Front, 1× USB3.2 Gen2 Rear, 1× USB3.2 Gen2x2 Rear Type-C, 1× USB3.2 Gen2 Type-C Front → Totals: Not aggregated. |
| Internal I/O Headers (key) | Internal I/O: 1× 24-pin ATX, 2× CPU_PWR, CPU fan, pump fan, 6× system fan, multiple USB headers, TBT connector, JDASH, addressable RGB, TPM header, EZ Debug LED. |
| Form Factor | ATX (243.84 × 304.8 mm) |
| Warranty | 3 Years |
