MSI B650M Gaming WIFI M-ATX Motherboard
Experience powerful gaming with the MSI B650 M Gaming WiFi AM5 Micro ATX Motherboard. Supports AMD Ryzen 7000/8000 series, DDR5 up to 7800+ MHz OC, PCIe 4.0, dual M.2 slots, Wi-Fi 6E, Bluetooth 5.3, 2.5Gb LAN, and 4K HDMI/DP output. Perfect for high-performance builds.
Original price was: ₹21,999.00.₹10,790.00Current price is: ₹10,790.00.
The MSI B650M Gaming WIFI is a gamer-oriented AM5 micro-ATX solution engineered to extract performance from Ryzen 7000/8000 series CPUs while enabling fast DDR5 operation. With dual M.2 slots, PCIe 4.0 lanes and a reinforced PCIe slot, it supports modern GPU and NVMe configurations. Networking includes a 2.5Gbps LAN interface and Wi-Fi 6E on supported models, which combined reduce latency for online competitive play and large asset transfers. Audio enhancements, sturdy power components and thermal protections such as heatsinks and M.2 shielding deliver a dependable platform for lengthy play sessions and streaming. MSI utilities provide both automated tuning and manual control, enabling builders to balance performance and noise profiles. This board is a strong fit for gamers who want a trimmed, feature-rich AM5 motherboard that fits into compact cases without sacrificing expansion. CTA: Get the MSI B650M Gaming WIFI at A2Z Computech — they offer verified warranty units, professional assembly, BIOS tuning and testing to ensure peak performance.
| Socket | AM5 |
|---|---|
| RAM | DDR5 |
| Form Factor | mATX (PCB dims listed) |
| CPU Support | AMD Ryzen™ 8000/7000 Series Processors |
| Socket | AM5 |
| Chipset | AMD B650 |
| Memory (Type/Slots/Max) | 2 x DDR5, Max. 96GB; DDR5 7800+(OC)/7600(OC)/…/4800 JEDEC, dual channel, non-ECC, EXPO™ |
| Graphics Out | 1 x HDMI 2.1 (4K 60Hz), 1 x DisplayPort 1.4 (4K 60Hz) |
| Expansion Slots | 1 x PCIe x16 (x16/x8/x4 by CPU), 1 x PCIe 3.0 x1 (chipset) |
| Storage (M.2/SATA) | 2 x M.2 PCIe 4.0 x4 (1 x4, 1 x4/x2 for 8500G), 4 x SATA 6Gb/s; RAID 0/1/10 on M.2/SATA |
| LAN | Realtek RTL8125BG 2.5Gbps LAN; Wi-Fi 6E (module pre-installed) |
| Wireless LAN / BT | AMD Wi-Fi 6E (pre-installed M.2 Key-E), Bluetooth 5.3 |
| USB (Rear + Front) | Rear: 2 x USB 2.0, 3 x USB 3.2 Gen1 Type-A, 1 x USB 3.2 Gen1 Type-C; Front: 4 x USB 2.0, 4 x USB 3.2 Gen1 Type-A |
| Audio | Realtek® ALC897, 7.1-channel HD Audio |
| Back Panel I/O Ports | DisplayPort, HDMI, 2.5G LAN, Wi-Fi/Bluetooth, audio connectors, Flash BIOS Button, USB 3.2 Gen1 (C/A), USB 2.0 |
| Internal I/O Connectors | ATX_PWR, CPU_PWR, PD_PWR1, 1 x CPU Fan, 3 x Sys Fan, 2 x JFP, 1 x JCI, 1 x JAUD, 2 x JARGB_V2, 1 x JRGB, 1 x TPM, 4 x USB 2.0, 4 x USB 3.2 Gen1 |
| Software Features | N/A |
| BIOS | N/A |
| Manageability | N/A |
| Accessories | N/A |
| Operating System | Windows® 11/10 64-bit |
| Warranty | 3 Years |
| Model | MSI B650M GAMING WIFI |
| CPU Support / Socket | AMD Ryzen 9000 / 8000 / 7000 (AM5) |
| Memory Support | 2 × DDR5 DIMMs (dual-channel) |
| Max RAM | Max 96 GB (listed) |
| Memory Type | DDR5 |
| Expansion Slots (PCIe) | 1 × PCIe x16 (CPU) ; 1 × PCIe x1 |
| Storage Support | 2 × M.2 (M.2_1 & M.2_2 both support PCIe4.0 x4 when CPU supports) ; 4 × SATA 6Gb/s |
| Graphics Output Options | 1 × HDMI ; 1 × DisplayPort ; 1 × D-Sub (listed) |
| Audio Codec | Realtek ALC897 Codec (7.1 HD) |
| USB Support (rear + front / totals) | CPU: 2 × USB3.2 Gen1 (back) + 1 × USB2.0 (back) ; Chipset/internal: 2 × USB3.2 Gen1 internal + 5 × USB2.0 etc — totals described in spec |
| Internal I/O Headers (key) | Front Type-C Quick Charge, CPU fan, 3 system fans, addressable & RGB headers, TPM header, Clear CMOS, M.2 socket, EZ Debug LED (listed) |
